Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt

Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt

  • Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
  • Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
  • Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
  • Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
  • Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt
Product Details:
Place of Origin: China
Brand Name: TOPONE
Certification: ISO9001:2015
Model Number: 201/302/304/316/316L
Payment & Shipping Terms:
Minimum Order Quantity: 1000KG
Price: Negotiation
Packaging Details: Coil/Pallet/Spool/By customere request
Delivery Time: 1-15 days
Payment Terms: D/P, Western Union, L/C, T/T
Supply Ability: >10000KGS per week
Contact Now
Detailed Product Description
Material: 201/302/304/316/316L Diameter: 0.15-12mm
Packing: By Customer Request Standard: JIS G. EN. ASTM. DIN. GB Etc
Surface: Bright Supply Ability: >500 Tons Per Month
Highlight:

12mm ss tig welding rod

,

0.15mm ss tig welding rod

,

316l mild steel binding wire

                               Stainless steel nail wire for screw and bolt non-magnetic
 Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt


Product Description

Over the years of experience in the industry, we have been able to provide the customers with an astounding assortment of  Stainless Steel Nail Wire. These wires are designed with utmost perfection in compliance with the international quality standards to attain highest benchmarks of quality. Available in different specifications and sizes, these wires are available at industry leading prices.

Features:


  • Super-fine stranded wire

  • Flame tested

  • Maximum flexibility



Specifications:
  • Size : 0.8mm to 6.0mm (0.031 to 0.236)
  • Grades : 304, 316, 304HC, 302HQ
  • Finish : Matt, Soap Coated
  • Temper : Soft, ¼ Hard
  • Packing : Coils 200-500 kgs, 2-3 Coils on carriers.




Mechanical properties




DIAMETER(MM)

TENSILE STRENGTH(MPA)ELONGATION(%)


SOFT-ANNEALED


SEMI-HARD


HARD

FOR SOFT-ANNEALED WIRE ONLY
0.20~0.30640~980__≥20
0.30~0.60590~930__≥20
0.60~1.00540~880830~11801180~1520≥25
1.00~3.00490~830780~11301130~1470≥25
3.00~6.00490~830730~10801080~1420≥30
6.00~14.00490~790730~1030_≥30



Physical Properties


Diameter Tolerance & Oval ToleranceMechanical Properties
(mm)Dia.(mm)Dia.ToleranceOval.Tolerance
0.030-0.050±0.003≤0.003
0.050-0.080±0.004≤0.004
0.080-0.10±0.005≤0.005
0.10-0.16±0.007≤0.007
0.16-0.28±0.010≤0.010
0.28-0.50±0.013≤0.013
0.50-0.90±0.015≤0.015
0.90-1.60±0.02≤0.02
1.60-2.80±0.03≤0.03
2.80-5.00±0.04≤0.04
5.00-9.00±0.05≤0.05
9.00-12.00±0.06≤0.06
12.00-14.00±0.07≤0.07

Type(mm)Dia(N/mm2)Tensilestrength(%)Elongation
SUS304.SUS304L0.02-0.05880-1130≥10
SUS316.SUS316L0.02-0.05650-900≥8
SUS304.SUS304L
SUS309S
SUS310S
SUS316.SUS316L
SUS321		0.05-0.16650-900≥20
0.16-0.50610-860
0.50-1.60570-820≥30
1.60-5.00520-770
5.00-14.00500-750
SUS304J30.05-0.16620-870≥20
0.16-0.50580-830
0.50-1.60540-790≥30
1.60-5.00500-750
5.00-14.00490-740




Chemical Composition


AISI GradeChemical Composition(%)
 CSiMnPSNiCrMo
304=<0.08=<1.00=<2.00=<0.045=<0.0308.00~10.5018.00~20.00-
304H>0.08=<1.00=<2.00=<0.045=<0.0308.00~10.5018.00~20.00-
304L=<0.030=<1.00=<2.00=<0.045=<0.0309.00~13.5018.00~20.00-
316=<0.045=<1.00=<2.00=<0.045=<0.03010.00~14.0010.00~18.002.00~3.00
316L=<0.030=<1.00=<2.00=<0.045=<0.03012.00~15.0016.00~18.002.00~3.00
430=<0.12=<0.75=<1.00=<0.040=<0.030=<0.6016.00~18.00-
430A=<0.06=<0.50=<0.50=<0.030=<0.50=<0.2514.00~17.00-




How to Enquiry Topone Stainless Steel Forming Wire in Efficiency
In order to quote you asap with right material in good price,we need you quote us with 10 details below .If you only know parts of them or only the wire application, you can talk with us online for help:



1Your wire applicationRequired
2Wire GradeRequired
7Wire Shape and SizeRequired
3Wire Surface FinishRequired
4Wire Tensile Strength LevelRequired
5Quantity/WeightRequired
6Wire Manufacturing StandardsRequired
8Wire TolerencePrefered
9Delivery TimePrefered
10Wire PackageOptional


Soft Raw Material For Wire Nail Nail Stainless Steel Wire For Screw And Bolt 0
