Bright Anneal 201 304 316 430 Stainless Steel Wire Price
Product Description
1. Name: Huayuan Stainless Steel Annealed Wire for making mesh
2. Size: Dia from 0.8mm to 15mm can be available
3. Certification: SGS Test Report & Follow ISO 9001:2015 Standard
| Product Name |
Matt Finish Stainless Steel Hydrogen Annealed Wire |
| Material |
Stainless 316/304/430/201 |
| Color |
Bright Or Matt |
| Standard |
ASTM A580, JIS G4309, EN 10088-3, GB/T4240 and Other Equivalents. |
| Grade |
Grade: 201, 202, 301, 302, 304, 304L, 304H, 304N, 316L, 321, 410, 420, 430 |
| Temper |
Annealed and Soft |
| Type |
Stainless steel annealed wire |
| Used |
industry machinery weaving |
APPLICATIONS
Stainless steel wire is mainly used in below fields:
1) Electric power, petroleum, boiler, high or low temperature resistant, corrosion resistant.
2) Tableware, cabinet, cutting tool, boiler, auto part.
3) Medical instruments, building materials, food industry.
4) Sea, chemical industry and machine manufacture.Or they can be made upon negotiation.
Physical Properties
| Diameter Tolerance & Oval Tolerance |
Mechanical Properties |
| (mm)Dia. |
(mm)Dia.Tolerance |
Oval.Tolerance |
| 0.030-0.050 |
±0.003 |
≤0.003 |
| 0.050-0.080 |
±0.004 |
≤0.004 |
| 0.080-0.10 |
±0.005 |
≤0.005 |
| 0.10-0.16 |
±0.007 |
≤0.007 |
| 0.16-0.28 |
±0.010 |
≤0.010 |
| 0.28-0.50 |
±0.013 |
≤0.013 |
| 0.50-0.90 |
±0.015 |
≤0.015 |
| 0.90-1.60 |
±0.02 |
≤0.02 |
| 1.60-2.80 |
±0.03 |
≤0.03 |
| 2.80-5.00 |
±0.04 |
≤0.04 |
| 5.00-9.00 |
±0.05 |
≤0.05 |
| 9.00-12.00 |
±0.06 |
≤0.06 |
| 12.00-14.00 |
±0.07 |
≤0.07 |
|
| Type |
(mm)Dia |
(N/mm2)Tensilestrength |
(%)Elongation |
| SUS304.SUS304L |
0.02-0.05 |
880-1130 |
≥10 |
| SUS316.SUS316L |
0.02-0.05 |
650-900 |
≥8 |
SUS304.SUS304L
SUS309S
SUS310S
SUS316.SUS316L
SUS321 |
0.05-0.16 |
650-900 |
≥20 |
| 0.16-0.50 |
610-860 |
| 0.50-1.60 |
570-820 |
≥30 |
| 1.60-5.00 |
520-770 |
| 5.00-14.00 |
500-750 |
| SUS304J3 |
0.05-0.16 |
620-870 |
≥20 |
| 0.16-0.50 |
580-830 |
| 0.50-1.60 |
540-790 |
≥30 |
| 1.60-5.00 |
500-750 |
| 5.00-14.00 |
490-740 |
|
Chemical Composition
| AISI Grade |
Chemical Composition(%) |
| |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
| 304 |
=<0.08 |
=<1.00 |
=<2.00 |
=<0.045 |
=<0.030 |
8.00~10.50 |
18.00~20.00 |
- |
| 304H |
>0.08 |
=<1.00 |
=<2.00 |
=<0.045 |
=<0.030 |
8.00~10.50 |
18.00~20.00 |
- |
| 304L |
=<0.030 |
=<1.00 |
=<2.00 |
=<0.045 |
=<0.030 |
9.00~13.50 |
18.00~20.00 |
- |
| 316 |
=<0.045 |
=<1.00 |
=<2.00 |
=<0.045 |
=<0.030 |
10.00~14.00 |
10.00~18.00 |
2.00~3.00 |
| 316L |
=<0.030 |
=<1.00 |
=<2.00 |
=<0.045 |
=<0.030 |
12.00~15.00 |
16.00~18.00 |
2.00~3.00 |
| 430 |
=<0.12 |
=<0.75 |
=<1.00 |
=<0.040 |
=<0.030 |
=<0.60 |
16.00~18.00 |
- |
| 430A |
=<0.06 |
=<0.50 |
=<0.50 |
=<0.030 |
=<0.50 |
=<0.25 |
14.00~17.00 |
- |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: We holding more than 1000tons in stock, generally it is 2-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=10000USD, 100% in advance. Payment>=10000USD, 30% T/T in advance ,balance before shippment.
If you have any further question, feel free to comments.
