Name: Durable Steel Nail Wire Loop Tie Wire Nickel White For Industry Machinery
Brand: Ningbo Huayuan Metal Products Co.,Ltd
SKU: 0.15mm-12mm
Price: 2.10 USD
Availability: InStock

Home Products Steel Nail Wire

Durable Steel Nail Wire Loop Tie Wire Nickel White For Industry Machinery

Product Details:

Place of Origin:	China
Brand Name:	TOPONE
Certification:	ISO9001:2015
Model Number:	0.15mm-12mm

Payment & Shipping Terms:

Minimum Order Quantity:	1000KG
Price:	Negotiation
Packaging Details:	Coil/Pallet/Spool/By customere request
Delivery Time:	1-15 days
Payment Terms:	D/P, Western Union, L/C, T/T
Supply Ability:	>10000KGS per week

Contact Now

Detailed Product Description

Material:	200/300/400	Diameter:	0.15-12mm
Packing:	By Customer Request	Standard:	JIS G. EN. ASTM. DIN. GB Etc
Surface:	Bright	Supply Ability:	>500 Tons Per Month
Highlight:	1.5mm Steel Nail Wire , 1.3mm Steel Nail Wire , 12mm stainless steel binding wire

Durable stainless steel wire for fastner, screws and nails
Durable Stainless Steel Nail Loop Tie Wire Nickel White For Industry Machinery

Durable stainless steel wire for screws and nails

1. Grade: SUS304 ,SUS310 ,SUS310S,SUS316,SUS302,SUS302B,SUS303Se
2. Size: 0.25 mm-15 mm
3. Certification: I S O 9001, REACH SVHC , ROHS

Product Name	Durable stainless steel wire for screws and nails
Material	Stainless steel
Color	nickel white
Standard	DIN GB ISO JIS BA ANSI
Grade	SUS304 ,SUS310 ,SUS310S,SUS316,SUS302,SUS302B,SUS303Se
Thread	coarse, fine
Used	industry machinery

Durable Steel Nail Wire Loop Tie Wire Nickel White For Industry Machinery 0

Mechanical properties

DIAMETER(MM)	TENSILE STRENGTH(MPA)			ELONGATION(%)
DIAMETER(MM)	SOFT-ANNEALED	SEMI-HARD	HARD	FOR SOFT-ANNEALED WIRE ONLY
0.20~0.30	640~980	_	_	≥20
0.30~0.60	590~930	_	_	≥20
0.60~1.00	540~880	830~1180	1180~1520	≥25
1.00~3.00	490~830	780~1130	1130~1470	≥25
3.00~6.00	490~830	730~1080	1080~1420	≥30
6.00~14.00	490~790	730~1030	_	≥30

Physical Properties

Diameter Tolerance & Oval Tolerance

Mechanical Properties

(mm)Dia.	(mm)Dia.Tolerance	Oval.Tolerance
0.030-0.050	±0.003	≤0.003
0.050-0.080	±0.004	≤0.004
0.080-0.10	±0.005	≤0.005
0.10-0.16	±0.007	≤0.007
0.16-0.28	±0.010	≤0.010
0.28-0.50	±0.013	≤0.013
0.50-0.90	±0.015	≤0.015
0.90-1.60	±0.02	≤0.02
1.60-2.80	±0.03	≤0.03
2.80-5.00	±0.04	≤0.04
5.00-9.00	±0.05	≤0.05
9.00-12.00	±0.06	≤0.06
12.00-14.00	±0.07	≤0.07

Type	(mm)Dia	(N/mm2)Tensilestrength	(%)Elongation
SUS304.SUS304L	0.02-0.05	880-1130	≥10
SUS316.SUS316L	0.02-0.05	650-900	≥8
SUS304.SUS304L SUS309S SUS310S SUS316.SUS316L SUS321	0.05-0.16	650-900	≥20
	0.16-0.50	610-860	≥20
	0.50-1.60	570-820	≥30
	1.60-5.00	520-770
	5.00-14.00	500-750
SUS304J3	0.05-0.16	620-870	≥20
	0.16-0.50	580-830	≥20
	0.50-1.60	540-790	≥30
	1.60-5.00	500-750
	5.00-14.00	490-740

Chemical Composition

AISI Grade	Chemical Composition(%)
	C	Si	Mn	P	S	Ni	Cr	Mo
304	=<0.08	=<1.00	=<2.00	=<0.045	=<0.030	8.00~10.50	18.00~20.00	-
304H	>0.08	=<1.00	=<2.00	=<0.045	=<0.030	8.00~10.50	18.00~20.00	-
304L	=<0.030	=<1.00	=<2.00	=<0.045	=<0.030	9.00~13.50	18.00~20.00	-
316	=<0.045	=<1.00	=<2.00	=<0.045	=<0.030	10.00~14.00	10.00~18.00	2.00~3.00
316L	=<0.030	=<1.00	=<2.00	=<0.045	=<0.030	12.00~15.00	16.00~18.00	2.00~3.00
430	=<0.12	=<0.75	=<1.00	=<0.040	=<0.030	=<0.60	16.00~18.00	-
430A	=<0.06	=<0.50	=<0.50	=<0.030	=<0.50	=<0.25	14.00~17.00	-

How to Enquiry Topone Stainless Steel Forming Wire in Efficiency
In order to quote you asap with right material in good price,we need you quote us with 10 details below .If you only know parts of them or only the wire application, you can talk with us online for help:

1	Your wire application	Required
2	Wire Grade	Required
7	Wire Shape and Size	Required
3	Wire Surface Finish	Required
4	Wire Tensile Strength Level	Required
5	Quantity/Weight	Required
6	Wire Manufacturing Standards	Required
8	Wire Tolerence	Prefered
9	Delivery Time	Prefered
10	Wire Package	Optional

Durable Steel Nail Wire Loop Tie Wire Nickel White For Industry Machinery 1
