Bending EPQ Wire 0.1-14mm Stainless Steel Wire AISI Standard Household General Use

Bending EPQ Wire 0.1-14mm Stainless Steel Wire AISI Standard Household General Use

Bending EPQ Wire 0.1-14mm Stainless Steel Wire AISI Standard Household General Use
video
Bending EPQ Wire 0.1-14mm Stainless Steel Wire AISI Standard Household General Use
Product Details:
Place of Origin: China
Brand Name: Toponewire
Certification: ISO9001:2015
Model Number: 201/302/304/316/316L
Payment & Shipping Terms:
Minimum Order Quantity: 500KG
Packaging Details: coil or spool with plate.
Delivery Time: 1-15 days
Payment Terms: D/P, Western Union, L/C, T/T
Contact Now
Detailed Product Description
Material: 201 304 201Cu Diameter: 0.15-12mm
Surface: Bright Or Soap Cotaed Packing: By Customer Request
Standard: JIS G. EN. ASTM. DIN. GB Etc Supply Ability: >500 Tons Per Month
Highlight:

0.1mm EPQ Wire

,

14mm EPQ Wire

,

316l 0.1 mm stainless steel wire

700-900MPa Stainless Steel Forming Wire super bright surface finishing




Electro-Polish Quality, EPQ wire has a brilliant mirror bright surface resulting in a radiant appearance when electro-polished. Stock material is provided with a 1/4 hard temper and cold drawn finish. Other tempers and sizes are available upon request. We also provide 201 stainless steel wire and 204Cu stainless steel wire as lower cost alternatives to traditional 304 stainless steel wire.

Now stocking domestic 304L and 316L stainless steel wire rod that can be processed with short lead times to non-stock sizes or to meet DFARS requirements.





Mechanical properties




DIAMETER(MM)

 TENSILE STRENGTH(MPA) ELONGATION(%)


SOFT-ANNEALED


SEMI-HARD


HARD

 FOR SOFT-ANNEALED WIRE ONLY
0.20~0.30 640~980 _ _ ≥20
0.30~0.60 590~930 _ _ ≥20
0.60~1.00 540~880 830~1180 1180~1520 ≥25
1.00~3.00 490~830 780~1130 1130~1470 ≥25
3.00~6.00 490~830 730~1080 1080~1420 ≥30
6.00~14.00 490~790 730~1030 _ ≥30



Physical Properties


Diameter Tolerance & Oval Tolerance Mechanical Properties
(mm)Dia. (mm)Dia.Tolerance Oval.Tolerance
0.030-0.050 ±0.003 ≤0.003
0.050-0.080 ±0.004 ≤0.004
0.080-0.10 ±0.005 ≤0.005
0.10-0.16 ±0.007 ≤0.007
0.16-0.28 ±0.010 ≤0.010
0.28-0.50 ±0.013 ≤0.013
0.50-0.90 ±0.015 ≤0.015
0.90-1.60 ±0.02 ≤0.02
1.60-2.80 ±0.03 ≤0.03
2.80-5.00 ±0.04 ≤0.04
5.00-9.00 ±0.05 ≤0.05
9.00-12.00 ±0.06 ≤0.06
12.00-14.00 ±0.07 ≤0.07

Type (mm)Dia (N/mm2)Tensilestrength (%)Elongation
SUS304.SUS304L 0.02-0.05 880-1130 ≥10
SUS316.SUS316L 0.02-0.05 650-900 ≥8
SUS304.SUS304L
SUS309S
SUS310S
SUS316.SUS316L
SUS321		 0.05-0.16 650-900 ≥20
0.16-0.50 610-860
0.50-1.60 570-820 ≥30
1.60-5.00 520-770
5.00-14.00 500-750
SUS304J3 0.05-0.16 620-870 ≥20
0.16-0.50 580-830
0.50-1.60 540-790 ≥30
1.60-5.00 500-750
5.00-14.00 490-740




Chemical Composition


AISI Grade Chemical Composition(%)
  C Si Mn P S Ni Cr Mo
304 =<0.08 =<1.00 =<2.00 =<0.045 =<0.030 8.00~10.50 18.00~20.00 -
304H >0.08 =<1.00 =<2.00 =<0.045 =<0.030 8.00~10.50 18.00~20.00 -
304L =<0.030 =<1.00 =<2.00 =<0.045 =<0.030 9.00~13.50 18.00~20.00 -
316 =<0.045 =<1.00 =<2.00 =<0.045 =<0.030 10.00~14.00 10.00~18.00 2.00~3.00
316L =<0.030 =<1.00 =<2.00 =<0.045 =<0.030 12.00~15.00 16.00~18.00 2.00~3.00
430 =<0.12 =<0.75 =<1.00 =<0.040 =<0.030 =<0.60 16.00~18.00 -
430A =<0.06 =<0.50 =<0.50 =<0.030 =<0.50 =<0.25 14.00~17.00 -




FAQ

Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: We holding more than 1000tons in stock, generally it is 2-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=10000USD, 100% in advance. Payment>=10000USD, 30% T/T in advance ,balance before shippment.
If you have any further question, feel free to comments.
